▎Features
Used to produce colorful and high wear resistant TPU sole.
Material tank with high-pressure resistance and large diameter can enable sole to be thinner and pattern to be clearer.
Advanced microcomputer control technology.
Hydraulic system with proportional control of pressure and flow makes machine action response faster, more efficient and energy-saving.
Stroke measuring system with high resolution guarantees that injection measurement and material-injection movement more accurate and more stable.
Closed-loop PID control of heating guarantees that temperature of raw materials is even and constant.
▎Technical Parameters
Model Of Machine | JG116/PU-TPU |
Station | 24/30 |
Mould Frame Size | 200*400mm 200*430mm |
Mould Clamping Force | 75KN |
Pu Feeding Quantity | 20-60g/s |
Tpu Plasticizing Quantity | 50cm³/s |
Tpu Screw Size | 65mm |
Pu Screw Size | 25mm |
